ADV NewsKTM Announces Specs & Pricing Of New 390 Enduro R Dual Sport

KTM Announces Specs & Pricing Of New 390 Enduro R Dual Sport

The orange brand finally releases details on the much-anticipated Enduro machine.

Published on 01.21.2025

KTM has officially unleashed one of the new off-road oriented 390 machines teased in recent months — the 390 Enduro R. The fresh dual sport features advanced electronics and, as a smaller sibling of the 690 Enduro R, KTM says it packs plenty of dirt capability, while also feeling at home in the urban jungle.

At the heart of the 390 Enduro R is the latest generation of KTM’s LC4c engine already transplanted in the 390 Duke range. This powerplant has been significantly redesigned with newly-optimized cylinder heads, repositioned fuel injectors and a revised gearbox, as well as meeting the latest emissions standards. The changes also introduce updated service intervals, with the first service occurring at 1,000 km, followed by regular services every 10,000 km thereafter. Valve checks are performed every 20,000 km.

KTM 390 Enduro R specs

The new 399 cc single-cylinder mill churns out 44 hp on the Enduro R, while torque numbers haven’t been provided yet (for reference, the updated engine delivers 28.8 lb-ft of torque on the Duke). The six-speed mill is complemented by a balancer shaft, PASC slipper clutch, and Ride-by-Wire system. Quickshifter+ is optional.

KTM 390 Enduro R specs

ADVERTISEMENT

Bump absorption is carried out upfront by a 43 mm WP APEX open cartridge fork delivering 230 mm (9.1 inches) of travel with adjustable compression and rebound in 30-click steps. Out back, an off-center WP APEX shock absorber boasts 20 clicks of rebound adjustability and 230 mm (9.1 inches) of travel, while preload is adjustable with the quick use of a tool. The new bike rolls on 21″/18″ spoked wheels, wrapped in Metzeler Karoo 4 rubber.

KTM 390 Enduro R specs

A unique, stainless steel exhaust design means the system fitted to the 390 Enduro R does not need an end muffler which has resulted in a total weight saving of 2 kgs (4.4 lbs). The new exhaust is equipped with a Double Catalyzer to comply with emissions regulations and features active control whereby the ECU not only adjusts the fuel mixture for optimal detonation but also adjusts the mixture to ensure an optimal temperature to reduce emissions. The active combustion system also works to detect any misfires, helping to diagnose the status of the catalytic converter and store information for OBDII diagnosis.

KTM 390 Enduro R specs

The new chassis design features a 2-piece steel trellis main frame and a bolt-on subframe. KTM says the frame design helps with vehicle dynamics by augmenting torsional rigidity, improving agility, and enhancing feedback from the chassis on both tarmac and dirt tracks. A gravity die-cast swingarm has been specifically developed for the KTM 390 Enduro R and provides a sturdy and durable platform for the rear suspension system.

KTM 390 Enduro R specs

Stopping power is delivered by 285 mm axial BYBRE brakes on the front and 240 mm single piston brakes on the back. The KTM 390 Enduro R also boasts a Bosch 10.3MB Modulator, which is the brain responsible for its ABS system. This enables standard ABS and an OFFROAD ABS option for dirt applications, which can also be completely disabled. MTC can also be completely turned off.

KTM 390 Enduro R specs

With an ergo triangle inspired by its bigger 690 sibling, the 390 Enduro R boasts offroad-ready bodywork made from flexible and long-lasting PP plastic material and a compact 2.37 gallon (9 liter) metal fuel tank. The new model also features an aggressive handlebar shape, all-new grippy footrests adjustable in two positions and a single-piece flat seat offering a seat height of 890 mm (35 in). The whole package tips the scale at a claimed 159kg (350 lbs) with fluids except fuel. (UPDATE: We’ve reached out to KTM and they have confirmed a fully fueled weight of 363 lbs).

KTM 390 Enduro R dual sport

In spite of its enduro styling the 390 Enduro R does not skimp on electronics, featuring selectable ride modes for versatility in different terrain. The bike also boasts a 4.2” TFT dashboard made from bonded glass with a special coating and polarization to reduce glare and increase visibility in all lighting conditions. Riders can also access music, incoming calls, turn-by-turn navigation and Ride modes via the dashboard.

KTM 390 Enduro R dual sport

The new dashboard is supported by completely redesigned switchgear featuring a 4-way Joystick with optimized ergonomics and illuminated switches. These allow riders to control various functions of the motorcycle, such as lights, indicators, and ride modes, and of course, interact with different connectivity features. The new switch cubes have an integrated and dedicated ABS-off switch.

KTM 390 Enduro R dual sport

Highlights

  • Single-cylinder 399 cc DOHC engine with electronic fuel injection, balancer shaft, PASC slipper clutch, Ride-by-Wire system and optional Quickshifter+.
  • 2-piece frame design is composed of a steel trellis main frame and bolt-on subframe, offering optimized rigidity.
  • Curved cast aluminum swingarm relocates the rear shock to lower the seat height and tuck in the exhaust.
  • 43 mm open-cartridge WP APEX front forks feature compression and rebound adjustability in 30-click steps.
  • Off-center, WP APEX Separate Piston shock absorber with 20 levels of rebound adjustment.
  • BYBRE brake system developed in cooperation with BREMBO.
  • Dual circuit BOSCH 10.3MB ABS is paired with Offroad ABS.
  • LED headlight, taillight, and turn signals with ATIR Automatic Turn Indicator Reset.
  • New 4.2-inch, full-color TFT display allows riders to toggle between ride modes, adjust the cornering-sensitive MTC, initiate Launch Control, and utilize KTMconnect.
  • New ride modes include Street and Offroad to adjust throttle response and traction control intervention.
  • New launch control maintains the revs with the throttle pinned.
  • Adjustable levers allow for proper reach for a variety of hand sizes.

Availability & Pricing

KTM has confirmed the 390 Enduro R is coming to North America in early 2025 with arrivals in Europe specifically announced for March. Pricing has been set with an MSRP starting at $5,499 USD.

2025 KTM 390 Enduro R

Engine Type:Single Cylinder, 4-Stroke, DOHC
Displacement:398.7 cc
Bore/Stroke:89/64 mm
Power:44.3 HP (33 kW)
Compression Ratio:12.6:1
Starter:Electric; 12V 8Ah
Transmission:6 Gears
Fuel System:Bosch EFI, 46 mm Electronic Throttle Body
Lubrication:Wet Sump
Cooling:Liquid Cooling
Clutch:PASC Slipper Clutch, Mechanically Operated
Ignition:Bosch EMS with Ride-By-Wire
Primary Drive:86:33
Secondary Gear Ratio:48:14
Chain:520 X-Ring
Frame:Steel Trellis
Subframe:Bolt-on
Handlebar:Aluminum, Tapered, Ø 26/22 mm
Front Suspension:WP APEX USD Ø 43 mm (Rebound, Compression and Preload Adjustable)
Rear Suspension:WP APEX Monoshock (Rebound Damping and Preload Adjustable)
Suspension Travel Front/Rear:230 mm/9 in; 230 mm/9 in
Front/Rear Brakes:Disc Brake 285 mm / 240 mm
Front/Rear Wheels:1.85 x 21”, 2.50 x 18”
Front/Rear Tires:90/90R21”; 140/80R18”
Steering Head Angle:62.9°
Wheelbase:1,475 mm ± 15.5 mm / 58 ± 0.6 in
Seat Height:890 mm / 35 in
Tank Capacity:9 L / 2.37 G
Weight (without fuel) Approx:159 kg / 350.5 lb

 Photos by Rudi Schedl
